Allows you to quickly adapt your company's computing system to changing business needs and ensure continued uptime, scalability and high profitability
Ideal for computing environments that use SANs and NAS and require rich management capabilities and convenient ways to connect to cloud services. Suitable for enterprise applications, virtualization, Microsoft solutions, and data backup and recovery.
Accelerate business operations and deliver an efficient total cost of ownership with the industry’s only unified, horizontally scalable storage architecture. For mission-critical and demanding workloads, we offer the FAS9000 Hybrid Storage Array with up to 7 million flash IOPS and up to several petabytes of disk capacity.
Model
Perfect for
HA pair form factor
Maximum amount of “raw” disk space
Maximum number of disks
FAS8300
Consolidation of heterogeneous loads with the required SLA
4U
11,5 UB
720 HDD (but no more than 480 SDD)
FAS8700
Performance-hungry applications while saving space
4U
15,0 PB
1440 HDD (but no more than 480 SDD)
NetApp FAS8300 Specifications
Form Factor
4U chassis with two HA controllers
Extension
Up to 12 HA pairs in NAS mode, up to 6 HA pairs in SAN mode
Software version
ONTAP 9.7RC1 or higher
Supported client OSs
Windows® 2000, Windows Server® 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016, Linux®, Oracle® Solaris, AIX, HP-UX, Mac® OS, VMware®, ESX®
Supported data network access protocols
CIFS, FC, iSCSI, NFS, NVMe/FC, NVMe/TCP, S3
Maximum number of SAS
720
Maximum number of SAS SSDs
480
Maximum number of SATA
720
Maximum volume of raw disk space
11,5 UB
Effective capacity
46 UB
Memory
256 GB
NVRAM
32 GB
PCIe expansion slots
14
100 Gbps Ethernet ports
4
Ethernet ports 25 Gbit/s
12
12 Gbit/s SAS ports
8
Characteristics of FAS8300 cluster configuration
Features
SAN
NAS
Scaling
6
12
Maximum number of disks (HDD/SSD)
2880
5760
Maximum volume of raw disk space
69,1 PB
138,2 PB
Effective capacity
276,4 PB
552,8 PB
Maximum memory capacity
1536 PB
3072 PB
FAS8700 Specifications
Form Factor
4U chassis with two HA controllers
Extension
Up to 12 HA pairs in NAS mode, up to 6 HA pairs in SAN mode
Software version
ONTAP 9.7RC1 or higher
Supported client OSs
Windows® 2000, Windows Server® 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016, Linux®, Oracle® Solaris, AIX, HP-UX, Mac® OS, VMware®, ESX®
Supported data network access protocols
CIFS, FC, iSCSI, NFS, NVMe/FC, NVMe/TCP, S3
Maximum number of SAS
1440
Maximum number of SAS SSDs
480
Maximum number of SATA
1440
Maximum volume of raw disk space
15 UB
Effective capacity
60 UB
Memory
512 GB
NVRAM
32 GB
PCIe expansion slots
14
100 Gbps Ethernet ports
4
Ethernet ports 25 Gbit/s
12
12 Gbit/s SAS ports
8
Characteristics of FAS8700 cluster configuration
Model
SAN
NAS
Scaling
6
12
Maximum number of disks (HDD/SSD)
2880
5760
Maximum volume of raw disk space
90 UB
180 UB
Effective capacity
360 UB
720 UB
Maximum memory capacity
3072 UB
6144 UB
